Ultra-Compact Micro Thermoelectric Cooler | TEC Module 1iTEC-017-050515
Model Number:1iTEC-017-050515
- Overview
- Applications
- Specifications
- Performance curves
- Mechanical Drawing
- Custom Options
- Recommended Products
The 1iTEC-017-050515 is an ultra-compact micro thermoelectric cooler with 17 couples, designed for precise temperature control in sensors, photonic devices, and laser systems.
It operates at 2.09V / 0.9A, making it ideal for applications with tight space and low power requirements.
Applications
Ideal for applications requiring silent, solid-state cooling in space-constrained or low-power environments, such as CCD sensors, optical transceivers, lab-on-chip devices, and miniaturized measurement instruments.
Specifications
PERFORMANCE CHARACTERISTICS （Th=298K@Vacuum）
|
△Tmax(K) |
73.1 |
|
Qmax(W) |
1.01 |
|
Imax(A) |
0.9 |
|
Umax(V) |
2.09 |
|
ACR(Ohm) |
2.09±0.21 |
|
Parameter deviation:+/-5% |
|
Performance curves
-
Voltage-Current characteristic
-
ΔT—F(Qc)
Other performance graphs are available on request;
Mechanical Drawing
Custom Options
Wire length: specified wire length & type.
Pellet Height Tuning：Adjusting pellet height changes performance:
• Higher: lower Imax, higher ΔT, lower Qmax
• Lower: higher Imax, lower ΔT, higher Qmax
Pre-Tinning：Solder type can be specified for assembly needs.
Note: Encapsulation is not recommended for multi-stage modules due to pressure risks in non-atmospheric environments.
